Product Codes: VGP20SH, VGP30SH, VGP40SH, VGP50SH, VGP60SH, VGP70SH, VGP80SH
Versatile Sealing Capabilities
Our solid silicone sheets are ideal for applications requiring excellent sealing in both high and low temperatures. We offer a wide range of hardness, thickness, colour options and adhesive backing.
Durable and Pure
Silicone is known for its durability and resistance properties, while being non-toxic and pure. It also provides excelling insulation and good release properties, making our solid silicone sheets the ideal choice for sensitive applications.
Broad Temperature Range
Unlike PVC, silicone maintained its useful properties even in sub-zero temperatures. Our solid silicone sheets are non-toxic, non-transferring, and feature a broad temperature range.
| Thickness | Translucent | White | Roll Width | Backing |
|---|---|---|---|---|
| 1mm | ✓ | ✓ | 1m | Plain / Adhesive |
| 1.5mm | ✓ | ✓ | 1m | Plain / Adhesive |
| 2mm | ✓ | ✓ | 1m | Plain / Adhesive |
| 3mm | ✓ | ✓ | 1m | Plain / Adhesive |
| 4mm | ✓ | ✓ | 1m | Plain / Adhesive |
| 5mm | ✓ | ✓ | 1m | Plain / Adhesive |
| Thickness | Translucent | White | Black | Red Oxide | Blue | Roll Width | Backing |
|---|---|---|---|---|---|---|---|
| 0.3mm | ✓ | ✓ | 1.2m | Plain / Adhesive | |||
| 0.5mm | ✓ | ✓ | 1.2m | Plain / Adhesive | |||
| 0.8mm | ✓ | 1.2m | Plain / Adhesive | ||||
| 1mm | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | ||
| 1.5mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 2mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 2.5mm | ✓ | ✓ | 1.2m | Plain / Adhesive | |||
| 3mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 4mm | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | |
| 5mm | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | |
| 6mm | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | |
| 8mm | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | |
| 10mm | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive | ||
| 12mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| Thickness | Translucent | Roll Width | Backing |
|---|---|---|---|
| 0.5mm | ✓ | 1.2m | Plain |
| 1mm | ✓ | 1.2m | Plain / Adhesive |
| 1.5mm | ✓ | 1.2m | Plain / Adhesive |
| 2mm | ✓ | 1.2m | Plain / Adhesive |
| 3mm | ✓ | 1.2m | Plain / Adhesive |
| 4mm | ✓ | 1.2m | Plain / Adhesive |
| 5mm | ✓ | 1.2m | Plain / Adhesive |
| 6mm | ✓ | 1.2m | Plain / Adhesive |
| 8mm | ✓ | 1.2m | Plain / Adhesive |
| 10mm | ✓ | 1.2m | Plain / Adhesive |
| Thickness | Translucent | White | Black | Red Oxide | Blue | Roll Width | Backing |
|---|---|---|---|---|---|---|---|
| 0.3mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain |
| 0.5mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain |
| 0.8mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 1mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 1.5mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 2mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 2.5mm | ✓ | ✓ | ✓ | v | ✓ | 1.2m | Plain / Adhesive |
| 3mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 4mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 5mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 6mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 8mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 10mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 12mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 15mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 20mm | ✓ | ✓ | ✓ | ✓ | ✓ | 1.2m | Plain / Adhesive |
| Thickness | Translucent | White | Roll Width | Backing |
|---|---|---|---|---|
| 0.5mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 1mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 1.5mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 2mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 3mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 4mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 5mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 6mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 8mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 10mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| 12mm | ✓ | ✓ | 1.2m | Plain / Adhesive |
| Thickness | White | Roll Width | Backing |
|---|---|---|---|
| 1mm | ✓ | 1m | Plain / Adhesive |
| 1.5mm | ✓ | 1m | Plain / Adhesive |
| 2mm | ✓ | 1m | Plain / Adhesive |
| 3mm | ✓ | 1m | Plain / Adhesive |
| 4mm | ✓ | 1m | Plain / Adhesive |
| 5mm | ✓ | 1m | Plain / Adhesive |
| 6mm | ✓ | 1m | Plain / Adhesive |
| 8mm | ✓ | 1m | Plain / Adhesive |
| 10mm | ✓ | 1m | Plain / Adhesive |
| 12mm | ✓ | 1m | Plain / Adhesive |
| Property | Units | VGP20SH | VGP30SH | VGP40SH | VGP50SH | VGP60SH | VGP70SH | VGP80SH | Test Method |
|---|---|---|---|---|---|---|---|---|---|
| Hardness | Shore A ±5 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | ASTM D2240 / DIN ISO 7619-1 |
| Tensile Strength | MPa(PSI) | 10.1 | 8.0 (1150) | 9.0 (1300) | 9.0 (1300) | 10.0 (1450) | 10.0 (1450) | 7.0 (1015) | ISO 37 type 1.ASTM D412 die C / DIN 53504 / Type S1 |
| Elongation to Failure | % | 979 | 500 | 525 | 450 | 400 | 320 | 215 | ISO 37 type 1 / ASTM D412 die C / DIN 53504 / Type S1 |
| Tear Strength | N/mm (lb./in.) | 25 | 16.0 (91) | 23 (130) | 18 (100) | 22 (125) | 20 (115) | 17 (88.5) | ASTM D624 die B |
| Compression Set 24 Hrs @ 150ᵒC | % | 23 | 23 | 25 | 15 | 13 | 9 | 18 | BS 903 pt A6 / type B / DIN/ISO 815 type B |
| Compression Set 22 Hrs @ 300ᵒF | % | – | 20 | 22 | 16 | 10 | 10 | 16 | ASTM D395 method B type 2 |
| Test | Result | Standard |
|---|---|---|
| Brittle Point | -80°C (-112 °F) | ASTM D746 |
| Limiting Oxygen Index | 24.0 % | BS 2782 Part 1 |
| Thermal Conductivity | 0.24 W.m⁻¹.K.1 | VDE 0304 |
| Radiation Resistance | >10⁵Grays (10⁷Rads) typical | |
| Dielectric Strength | 23 kV.mm⁻¹ | VDE 0303 |
| Dielectric Constant | 2.9 | VDE 0303 |
| Dissipation Factor | 3×10⁻⁴ | VDE 0303 |
| Volume Resistivity | 3×10¹⁵Ω.cm | VDE 0303 |
