Unmatched Transparency
Our clear silicone sheets are the only are the only sheeting product that offers ‘glass clear’ transparency while maintaining excellent durability and flexibility.
High-Quality Manufacturing
Glass clear silicone sheets are manufactured from centrifugally using platinum cured silicone. This process ensures sheets are non-toxic, non-yellowing, and free from peroxide by-products, maintaining their transparency for as long as possible.
| Nominal Thickness | Tolerance |
|---|---|
| mm (inches) | mm (inches) |
| 0.254 (0.010) | ± 0.051 (±0.002) |
| 0.508 (0.020) | 0.076/-0.051 (+0.003/-0.002) |
| 0.787 (0.031) | ± 0.102 (±0.004) |
| 1.600 (0.063) | ± 0.152 (±0.006) |
| 3.172 (0.125) | ± 0.203 (±0.008) |
| Property | Unit | Test Method | Typical Value | Specification |
|---|---|---|---|---|
| Colour | Visual | Transparent | – | |
| Thickness | mm (inches) | Internal | 0.250 – 3.18 (0.010 – 0.125) | – |
| Specific Gravity | g/cm³ | Internal | 1.07 | – |
| Durometer | Shore A | ASTM D2240 | 41 | 40 ± 5 |
| Compression Set | % | ASTM D395 150ᵒC (302ᵒF / 70 hrs / 25%) | <35 | – |
| Tensile Strength | MPa (psi) | ASTM D412 | 7.17 (1040) | >4.8 (>700) |
| Elongation | % | ASTM D412 | 325 | >200 |
| Tear Resistance | ppi | ASTM D624 | 112 | >70 |
These figures are only intended as a guide and should not be used in preparing specifications.
| Property | Unit | Test Method | Typical Value | Specification |
|---|---|---|---|---|
| Dielectric Strengt | Volts/mil | ASTM D149 | 386 | – |
| Dielectric Constant | 1 kHz | ASTM D150 | 2.76 | – |
| Dissipation Factor | 1 kHz | ASTM D495 | 0.003 | – |
| Dry Arc Resistance | Seconds | ASTM D495 | 124 | – |
| Volume Resistivity | Ω·cm | ASTM D257 | 1014 | – |
These figures are only intended as a guide and should not be used in preparing specifications.
| Property | Unit | Test Method | Typical Value | Specification |
|---|---|---|---|---|
| Temperature Range | ᵒC (ᵒF) | Internal | -55 to + 200 (-67 to +392) | – |
| Thermal Conductivity | W/mᵒK | ASTM D518 | 0.21 | – |
| Low Temperature Brittleness | – | ASTM D2137-62ᵒC (-80ᵒF) / 3 min | Pass | – |
These figures are only intended as a guide and should not be used in preparing specifications.
